 Horsepower 450 HP - 750 HP
Displacement 2.0 L - 4.5 L
- Ball bearing.
- Forged, fully-machined compressor wheel featuring next-generation GTX aerodynamics.
- Oil & Water
cooled bearign system.
- Compressor wheel is 11 full-blade design.
- Compressor housing features a ported shroud.
- T4 turbine inlet flange and V clamp outlet flange.
- This unit is outline interchangeable on turbine side with GT3582R.
- Ideal for twin-turbo applications on engines making 1500 hp.
Note: The 803715-0001 GTX3582R is a customizable Garrett ball bearing GT turbo that is packaged without the turbine housing. (It includes a CHRA and compressor housing.)
Turbo Dimensions (138 Kb)
| GTX3582R |
COMPRESSOR |
TURBINE |
| Turbo |
CHRA |
Inducer |
Exducer |
Trim |
A/R |
Wh Dia |
Trim |
A/R |
Type |
| 803715-0001 |
706451-0034 |
62.5
mm |
82.5
mm |
58 |
0.70 |
68.0
mm |
84 |
- |
- |
ACCESORIES
TURBINE HOUSING (T3 - 4-bolts)
TURBINE HOUSING (T3 - V clamp)
| Outlet |
| Part Number |
Description |
| 446397-0362 |
V clamp |
| 774175-0001 |
Flange |
TURBINE HOUSING (Stainless steel - V clamp)
TURBINE HOUSING (T4 - V clamp)
| Outlet |
| Part Number |
Description |
| 446397-0362 |
V clamp |
| 774175-0001 |
Flange |
TURBINE HOUSING (T3 - 5-bolts)
| Outlet |
| Part Number |
Description |
| 210980 |
Gasket |
| 219017 |
Flange |
BEARING HOUSING
| Inlet |
| Part Number |
Description |
| Not used |
Gasket |
| 431863-0006 |
Oil fitting HiPer |
| 210750 |
Water fittings kit |
|
